Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
  • Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
  • Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh
  • Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh

Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh

Protection Class: IP65
Grid Connection: Hybrid Grid
Nominal Voltage(V): 51.2V
Working Voltage(V): 42V~58.4V
Nominal Capacity(Ah): 1000Ah,200Ah
Contact Us
10.24KWh
Nominal Power
Specifications
Payment & Shipping Terms
Product Description
Specifications
Protection Class: IP65
Grid Connection: Hybrid Grid
Nominal Voltage(V): 51.2V
Working Voltage(V): 42V~58.4V
Nominal Capacity(Ah): 1000Ah,200Ah
Nominal Power: 10.24KWh
Highlight:

Energy Storage Lithium ion Batteries 15KWh

,

LiFePo4 Energy Storage Lithium ion Batteries

,

Hybrid Grid LiFePo4 Energy Storage Battery
Payment & Shipping Terms
Minimum Order Quantity: 10
Price: negotiated price
Packaging Details: solar power station carton packaging
Delivery Time: 5-14 work days
Payment Terms: Western Union, MoneyGram
Supply Ability: 1000+PCS+1000 per week
Product Description

LiFePo4 Pack 100Ah 200Ah 5KWh 10KWh 15KWh Battery Energy Storage Lithium ion Batteries

  The 51.2V 100Ah battery system is applicable to home energy storage, small or medium sized shopping mall energy storage,which uses 32 pieces of 3.2V 100Ah battery cells in 16s1p configuration.Built-inSeplos smart BMS suppor tmaximumof 16packs of battery in paralleltoachieve high ercapacity.The system can not becon nected in series.And do not mixusea ocell battery with anyother battery brands or models.

  O'Cell is committed to providing high-quality solar inverter solutions that help to power a greener future. With its advanced technology,flexible design, and user-friendly interface, [Inverter Model] is the ideal choice for anyone looking to harness the power of the sun and make the switch to clean, renewable energy.

Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh 0

Solar Inverter Characteristics

1.C16-cell battery voltage sampling test, with deviation of ±20mV
2.Battery and ambient temperature detection: 4 battery temperature sensors, 1 ambient temperature sensor, and 1 MOS temperature sensor, with a deviation of ±2°C.
3.Battery capacity and cycles: Complete a full charge/discharge cycle to set the actual capacity. The remaining capacity of the battery is monitored with a capacity estimation accuracy within 5% deviation. Additionally, charge and discharge cycle times as well as full charge and discharge cycle times are configurable
4.Intelligent cell balancing: The charging and static balancing strategies can be set flexibly to effectively extend the service life.
5.Communication port: PC or smart front-end can monitor battery pack data, control operation and set parameters through commands such as telemetry, remote signaling, remote adjustment, and remote control. The communication protocol conforms to the requirements of YD/T 1363.3, and realizes cascade communication at the same time.
6.Communication interface: PC or intelligent front-end can monitor battery data, control operation and set parameters through telemetry, remote signaling, remote adjustment, remote control and other commands. The communication protocol meets the requirements of YD/T 1363.3 and realizes cascade communication
Items
Specifications
BatteryConfiguration
1P16S
NominalVoltage
51.2V
WorkingVoltageRange
42V~58.4V
NominalCapacity
100AH
NominalPower
5.12KWh(95%DOD)
StandardCharging/Discharging Current
50A@25±2℃
MaximumChargingCurrent
100A@25±2℃
MaximumDischargingCurrent
100A@25±2℃
WorkingAmbientTemperature
0～45℃(Charge)
-10～40℃(Discharge)
StorageTemperature&Humidity
-10℃~35℃(within1monthstorage)
25±2℃(within3monthsstorage)
65%±20%RH
Size(LxWxH)
(563)×(399)×(162)mm
Weight
48Kg±3kg
Cycling Lifespan
6000 cycles @25℃ 50A Charging/discharging current 80%DOD
IP Rate
IP 65
Communication
CAN or RS485
Altitude
0-3000m
Humidity Range
5~80%



Hybrid Grid LiFePo4 Energy Storage Lithium Ion Batteries 100Ah 200Ah 5KWh 10KWh 15KWh 1

1. What is an energy storage battery?

An energy storage battery is a device that stores electrical energy in the form of chemical energy and releases it as electrical energy when needed. It is used to store surplus energy generated from renewable sources or during low-demand periods for later use.

2. What are the common types of energy storage batteries?
Common types of energy storage batteries include lithium-ion, lead-acid, nickel-cadmium, and flow batteries. Lithium-ion batteries are the most widely used in residential and commercial applications.

3. Why are energy storage batteries important?
Energy storage batteries play a crucial role in stabilizing the electrical grid, managing energy supply and demand, and increasing the efficiency of renewable energy sources by storing excess energy for use during peak demand periods.

4. How long do energy storage batteries last?
The lifespan of an energy storage battery varies depending on the type and usage but typically ranges from 5 to 20 years.
Lithium-ion batteries often have a lifespan of 10-15 years.

5. Can energy storage batteries be used for off-grid applications?
Yes, energy storage batteries are commonly used in off-grid and remote locations to provide a reliable source of electricity when there is no access to the main grid.

6. Are energy storage batteries environmentally friendly?
Energy storage batteries can be environmentally friendly, especiallywhen used with renewable energy sources. However, it's essential to consider the environmental impact of battery production and disposal.
